Large Size Baler Range


large size baler range

Product Features

  • Bale weight from 550 to 650 Kgs.
  • Hydraulic bale eject
  • Volume reduction of up to 90%
  • Grabbers to prevent spring back
  • Large feed opening
  • Powder coat baked paint finish
  • 3 phase 380 – 400v
  • Slotted bottom door for easy tying
  • Indoor / Outdoor use
  • CE compliant
  • Reduced Disposal Costs
  • Facilitates Recycling
  • Cleaner Work Place
  • Lower Labour Costs


Ceco 550, 550HD, 650 & 70T Horizontal Balers

The Ceco 550, 550HD, 650 and 70T Horizontal Balers make up our large sized range producing bales from 550 to 650 Kgs. These machines will bale cardboard, plastic, paper, tyres, car bumpers, hard plastics such as computer monitors / cases, etc. and are suitable for very large producers, Council Yards, Recyclers, Shopping Centres, Factories, Etc. All four of these balers have hydraulic bale eject as standard. The 70T Horizontal is available with an optional Bin Lifter or Feed Conveyor. The machines are fully CE compliant and supplied complete with warranty. Built strong these machines are ideal for the large producer with a lot of material to process.

REDUCE REUSE RECYCLE with products from Ceco Equipment

Specifications
  Ceco 550 Baler Ceco 550HD Baler Ceco 650 Baler Ceco 70T Horiz. Baler
Motor 11 kW 32amp 11 kW 32amp 11 kW 32amp 22 kW 63amp
Electrical 380 - 400V
Three Phase 50Hz		 380 - 400V
Three Phase 50Hz		 380 - 400V
Three Phase 50Hz		 380 - 400V
Three Phase 50Hz
Maximum Compaction Up to 50 Tonnes Up to 50 Tonnes Up to 50 Tonnes Up to 70 Tonnes
Bale Weight Up to 550 Kgs. Up to 610 Kgs. Up to 650 Kgs. Up to 600 Kgs.
Bale Size
(W x D x H) mm		 1500 x 769 x 1200 1500 x 769 x 1200 1500 x 1100 x 1100 750(H) x 1100(D) x 1200 – 1500(L)
Machine Dimensions
(W x D x H) mm		 2115 x 1200 x 3217 2115 x 1200 x 3500 2115 x 1524 x 3217 6907 x 1782 x 2008
(height includes hopper)
Transport Height
Ram Lowered		 2500mm 2500mm 2500mm 2008mm
Weight 1650 Kgs. 1935 Kgs. 1930 Kgs. 7700 Kgs.
Loading Aperture
(W x D x H) mm		 1500 x 769 x 880 1500 x 769 x 880 1500 x 1100 x 883 1200 x 1009
Rolls of Bale Strap 5 wire or strapping 5 wire or strapping 5 wire or strapping 5 wire
Bale Ejection Hydraulic Tipping Hydraulic Tipping Hydraulic Tipping Hydraulic Full Eject
